FREESCAN X5

Category: Product/Hardware Sales & Support, Shining 3D

 Product Description

  • Light body and easy operation : Light and handy (0.8kg), narrow space operation accessible, external clamping positioning no needed;
  • Large measurement space : Almost unlimited 3D scanning, not affected by size, texture and color of the object;
  • High accuracy, high speed : Accuracy up to 0.03mm, under German VDI/VDE 2634 standard. High speed scanning: 240000 scans/s;
  • High compatibility : Compatible photographic 3D photogrammetric systems, measuring large workpiece



SPECIFICATION

Model FreeScan X5
Weight 0.8 (kg)
Size 135 x 80 x 300 (mm)
Light source 10 line laser array, Class II (eye safe)
Scan rate 350000(scans /s)
Scanning area 250 x 250 (mm)
 Resolution 0.100 (mm)
 Measurement accuracy Maximum 0.03 (mm)
 Volume precision 0.020 + 0.100 (mm / m)
Volume precision
(combined with DigiMetric)
0.020 + 0.025 (mm / m)
 Working distance 300 (mm)
Scan depth 250 (mm)
 Measurement range 0.1 – 6 (m), extendable
(object size)
Data compatibility software 3D System(GeomagicSolutions, InnovMetric Software(PolyWorks), DassaultSystemes
(CATIA V5& SolidWorks, PTC(Pro/ENGINEER), Siemens(NX和Solid Edge
Autodesk(Inventor, Alias, 3ds Max, Maya, Softimage)
Transmission mode USB3.0
Working temperature -10 – 40 ℃
Working humidity 10 – 90 %
